Description

Innoptical’s IN-AOC-100G-DXXX is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. The AOC offers 4 independent data transmission channels and 4 data receiving channels via the multimode ribbon fibers, each capable of 25Gb/s operation. Consequently, an aggregate data rate of 100Gb/s over 100 meters transmission can be achieved by this product, to support the ultra-fast computing data exchange.

Spotlights

  • QSFP MSA compliant
  • Four independent full-duplex channels
  • Supports 103.1Gb/s aggregate bit rate
  • Up to 100m OM4 MMF transmission
  • Operating case temperature: 0 to 70oC
Get an Instant Quote
Free Sample
Fully customized
Low MOQ: 1pcs
Free design
Distribute Globally

Specification

Data Rate(Gb/s)100G
Tx850nm VCSEL
RxPIN
Transmitter Power (dBm)1 Min-5
Transmitter Power (dBm)1 Max2.4
Receiver Power (dBm)1 Min-6
Receiver Power (dBm)1 Max2.4
Max Power Consumption(W)2.5 (each QSFP28)
Reach1~100m
Temperature (deg C)0~70
